Product Category:Latching Solenoid
Rated Voltage:DC 12V/(Customized)
Rated Power:32w
Rated Stroke:8mm(Customized)
Temperature Rise:65℃ Max
Duty Circle:25%
Work Life:0.5 million cycle(10% )
Dimension:40*29*24mm
The working principle of the latching solenoid is based on the combination of an electromagnet and a mechanical structure. When the electromagnet is energized, it generates magnetic force to attract the iron core, causing the valve to open; when the electromagnet is de-energized, the iron core is reset by the spring and the valve is closed. This design allows the valve to remain closed after power failure without the need for continuous power supply, thereby saving energy and ensuring that it remains safe even in the event of a power failure.
The specific structure of the latching solenoid includes:
1.2.1-Coil: When powered on, it generates a magnetic field to attract the iron core to move.
1.2.2-Iron core: It is attracted by the coil and moves to the working position. After power is off, it is held in this position by the holding mechanism.
1.2.3-Holding mechanism: It is usually a spring or magnetic material that ensures that the iron core remains in the working position.
The main features of Latching Solenoid include:
1.3.1-Self-locking function: It can maintain its position after power failure, without continuous power supply.
1.3.2-Compact design: It is usually small in size and suitable for use in limited spaces.
1.3.3Multiple applications: It is suitable for various occasions that require precise control and space saving, such as home kitchens, bathrooms, etc.
| Specifications | |||
| Brand | Customized | Product Name | Latching solenoid |
| Model | SFLS-005 | Rated Voltage | DC 12v |
| Power | 32w | Force | 0-10N |
| Stroke | 0-8mm | Duty Cycle | 25% |
| Cable Length | 200mm | Material | Metal, Electronic Parts |
| Action Form | Push pull type | Weight(N.W.) | 0.35kg |
| Install Style | Screw | Thread Size & Deepth(mm) | 8-M3 |
| Hi-Pot Test | AC 600V 50/60Hz 2s | Insulation Class | B |
Strong spring toughness is high, repeated use is still elastic, to ensure that each expansion can be fast in and out
Using the national standard copper coil, wound core components, faster heat dissipation, low power consumption, low temperature, long time use, improve the efficiency of the electromagnet and extend the life
Easy and convenient installation,the screw thread is fixed, the installation is stable, the disassembly is convenient, saving time and labor
Good heat dissipation performance:The use of high quality raw materials, durable, good heat dissipation, not afraid of large temperature difference changes, no remanent magnetic power
The Dc Mini Latching Solenoid electromagnet is a non-standard customized electronic component. Except for the coil frame which is molded, other accessories and parameters can be customized as required.
Customization process:
4.1. Contact us: Please send an email or WhatsApp to contact us(+86 18902611680)
4.2. Provide requirements: Provide parameters such as voltage, force, stroke, on-off ratio and size.
4.3. Specification confirmation: We select and issue specifications according to requirements. Except for the outer frame size, other shaft sizes and lengths can be customized. If it is made according to a specific outer frame size, a mold needs to be opened.
4.4. Proofing: We make samples according to the specifications, and the production cycle is about 7 days.
4.5. Sample testing: If the sample test is qualified, a batch order will be placed. If it is unqualified, the sample will be remade.
4.6. Mass production: Sign a bulk purchase and sale contract.
Our headquarters is located in Guangdong, China. Since 2015, we have developed and produced electromagnets and sold them to North America (35.00%), South Asia (25.00%), Western Europe (20.00%), South America (15.00%), Northern Europe (5.00%).
We are a Chinese top manufacturer and our factory is located in Dongguan. Welcome to visit our factory!
We pecialize in the design and production of high quality electromagnet,solenoid valve,such as rotary solenoid bistable solenoids latching solenoids open frame solenoids tubular solenoids self-holding solenoid
•Of course, usually we will provide free samples, and you only need to cover the freight. For custom electromagnet samples, pls send your requirements to us for checking the sample cost.
• It takes about 7 days for sample production.
Yes, we provide free design services, structural design and simple graphic design.
Sure. We can do any electromagnet with your design. Now we open a ODM solenoid which is for small quantity from 100pc to 500pc,but you can still have your own logo.
Depending on the order quantity and production details, it will take about 15 to 20 days.
Always a pre-production sample before mass production; Always final Inspection before shipment
• Power,usage,size, material, quantity, shipping destination, etc.
• You can also just tell us your requirements and we will recommend products to you.
• By sea, by air or by express.
• If you have your own freight forwarder in China, it is the ex-factory or FOB price.
•CFR or CIF, etc., if you need us to ship on your behalf.
• DDP and DDU can also be used.
• More choices, we will consider your choices.
Use our professional design experience to customize your brand electromagnet!
